Home > Products > Blower Filter Unit(Return )








The Blower Filter Unit (Return) is installed on the ceiling and is a kind of clean unit with a filter and a fan, providing a high cleanliness level with a HEPA Filter Unit.

Up to 32 units can operate separately using an M.C.U. Controller and a high cleanliness level is maintained by the adjustment of wind velocity.

: Hospital (Operating Room, Dust-Free Room, etc.) and Clean Room (Electronic Semi-Conductor, etc.)





  • The unit itself provides clean air.
  • Various cleanliness levels are available depending on how to install or the number of installation(s).
  • A clean room may be built relatively easily regardless of the shape of building.
  • No return duct is required, reducing the construction cost.
  • The installation is easy and speed control is available (0 to 100%).






Spec/ Model
SG-BFU1CW
SG-BFU2CW SG-BFU3CW SG-BFU4CW

Body
780x780x650H 780x780x750H 780x1085x620H 670x1390x750H
Casing and Check Hole: Steel Plate Melamine Coating 1.2t
Punching Plate:Steel Plate Melamine Coating 1.0t or Stainless 1.0t
Sound-Absorbing Material 20t, Finished by a Porous Plate
Filter
Blower Filter DOP Test 99.97% or higher
610x610x150t 610x610x292t 610x915x150t 610x1220x150t
Fan
Turbo Impeller(Backward Wheels)Type
Air Volume(CMM)
17 32 26 35
Sound Level(dB)
35~50
Áß·®(kg) 45 47 51 55

* The Wind Volume of a Filter is based on the standard filter.
* In addition to the specification above, various types are available according to order
